The performance of each component of a luminaire is demonstrated through its efficiencies, which together determine the total system efficiency of the product. The output of the LED chip is first multiplied by the optical and thermal efficiencies to calculate the Luminaire efficiency. However, this calculation does not consider the driver efficiency. To determine the overall efficiency of the system, the Luminaire efficiency must be multiplied by the driver efficiency, which accounts for all losses in the system.
Mechanical
Adjustability
Adjustable
Body Material
Aluminium
Diffuser Material
Glass
Product Finish
Powdercoated
Fitting Colour
Black
IK Rating
IK08
Installation Type
Surface mount
IP Rating
IP66
Electrical
Earth Leakage
0.75 mA
Electrical Rating
Class I
Input Frequency
50 Hz
Input voltage
230Vac
In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6%
