In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6%
Maximum Wattage
EV-RAZOR-TK-ADV-B-LK
2 W
EV-RAZOR-TK-ADV-LK
2.6 W
Standby Power
EV-RAZOR-TK-ADV-B-LK
1.7 W
EV-RAZOR-TK-ADV-LK
1.9 W
Standby power for non-maintained/switched maintained emergency devices is measured when the light is off and the charger is in standby mode. For maintained emergency devices, standby power is measured when the light is on and the charger is in standby mode. Typically, charging occurs for the first 16 hours after the device is powered or after a battery discharge.
Working Temp Range
0 to 40 °C
Driver
Dimmable
No
Driver Included
Yes
Integrated Driver
Yes
Wiring Type
Re-wireable terminal block (5 pin)
Emergency (EM suffix)
Replacement Battery Code
13972
Emergency Control
IEC62386-104 (Wireless DT1)
IEC62386-104 ~ Supports wireless test and monitoring over IEC62386-104 using IEC62386-202.
Decal Size
300 x 150 mm
Emergency Duration
90 mins
Emergency Light Source Life
EV-RAZOR-TK-ADV-LK
34Y/04M
EV-RAZOR-TK-ADV-B-LK
51Y/01M
AS2293.3-2018 Projection of Light source life for LED Exit signs (appendix E) Defines the projected time until the surface luminance falls below the minimum required surface luminance for an exit sign.
